Advanced Mercurial Debugging

An in-depth look at debugging Mercurial using a real-world issue.

Overview

While revising From git to hg, I ran into a blocking issue while working on CPython’s Mercurial repository. This is the process I used to identify the problem and possible solutions. The details are specific, but the approach helps diagnose other Mercurial HTTP(S) failures.

The problem

After finishing one bookmarked issue, returning to the last public default-branch commit, and committing work on another, a pull failed:

$ hg pull
pulling from https://hg.python.org/cpython
searching for changes
abort: HTTP Error 400: Bad request

More logging did not initially make the source of the problem obvious:

$ hg pull --debug -vv
using https://hg.python.org/cpython
sending capabilities command
pulling from https://hg.python.org/cpython
preparing listkeys for "bookmarks"
sending listkeys command
query 1; heads
sending batch command
searching for changes
taking initial sample
query 2; still undecided: 10624, sample size is: 200
sending known command
abort: HTTP Error 400: Bad request

Searching for answers

Searching for the error led to a post by Ilia Barahovsky. The affected repository used HTTPS and I did not have its private keys, so packet inspection could not reveal application data.

Digging deeper

Mercurial is Python, so I followed the source and set a breakpoint in mercurial.httppeer.httppeer._callstream. Inspecting the caught error in pdb showed only the server response:

(Pdb) inst.read()
'<html><body><h1>400 Bad request</h1>\nYour browser sent an invalid request.\n</body></html>\n\n'

The request object exposed the relevant clue: its X-hgarg-* headers contained serialized node IDs. Measuring the serialized headers showed their size:

(Pdb) len('\r\n'.join('{}: {}'.format(k, v) for k, v in req.headers.items()))
8417

That aligned with the earlier report. Web servers impose different default header-size limits. Discussion with #python-dev identified HAProxy’s tune.maxrewrite setting as the immediate culprit: bufsize - tune.maxrewrite could not accommodate the request headers.

A note on debugging without working from source

Using a tagged source checkout of Mercurial makes it easy to modify and contribute fixes. But debugging an installed copy is also straightforward because it is interpreted Python:

>>> import mercurial
>>> mercurial.__file__
'/Library/Python/2.7/site-packages/mercurial/__init__.pyc'

The containing directory holds the source files. Open and edit them as needed, perhaps with elevated permissions.

How did it come to this?

The traceback led from commands.pull through exchange, discovery, and wireproto to the HTTP peer. The key call was:

yesno = remote.known(dag.externalizeall(sample))

sample held 200 revisions. dag.externalizeall(sample) produced node IDs; mercurial.wireproto.wirepeer.known hex-encoded them. Those values became the X-hgarg-* request headers.

So what does this tell us?

When a remote head does not know about a local head, Mercurial compares the local head’s history in samples. The default is 200 commit hashes per request, and the hashes are sent as HTTP headers. In this case, the worst-case request-header size was roughly 8.5 KB, including Content-Length.

The solution

This problem requires all of the following:

Mercurial over HTTP(S).
A local head that the remote does not know.
Enough commits to exceed the host or proxy header limit.
A server or proxy with a limit lower than the resulting request headers.

The solution is to increase the application server or proxy header-size limit above the headers generated in the worst case.
